1.5 Ton Diesel Forklift

The 1.5 Ton Diesel Forklift is a powerful and efficient machine designed to handle heavy loads with ease. It is perfect for use in warehouses, construction sites, and manufacturing facilities. With its robust construction and reliable performance, this forklift is built to withstand demanding work environments.

Inquire Now Next Product

Features
Specifications

Powerful Performance: The 1.5-ton capacity allows for lifting and transporting heavy loads with precision and efficiency.

Diesel Engine: The forklift is equipped with a reliable diesel engine, providing excellent power and torque for smooth operation.

Durable Build: The forklift is constructed with high-quality materials, ensuring durability and long-lasting performance.

Easy Maneuverability: With its compact design and responsive controls, the forklift offers excellent maneuverability in tight spaces.

Operator Comfort: The ergonomic design of the cabin provides a comfortable working environment for the operator, reducing fatigue during long hours of operation.

Safety Features: The forklift is equipped with safety features such as a seat belt, horn, and LED lights to ensure the safety of the operator and others in the vicinity.

Versatile Applications: The forklift is suitable for a wide range of applications, including loading and unloading goods, stacking pallets, and transporting materials.

General	1	Manufacturer		BeiJing Vicgordan Industrial Co., Ltd
	2	Model		FD15C	FD15J	FD15J
	3	Power Type		Diesel	Diesel	Diesel
	4	Rated Load Capacity	Q(kg)	1500	1500	1500
	5	Load Centre	C(mm)	500	500	500
Characteristic & Dimension	6	Rated Lift Height	H3(mm)	3000	3000	3000
	7	Free Lift Height	H2(mm)	100	100	100
	8	Fork Size (L×W×T)	mm	920×120×35	920×120×35	920×120×35
	9	Mast Tilt Angle (F/R, α°/β°)	deg	6°/12°	6°/12°	6°/12°
	10	Fork Overhang (Wheel Center to Fork Face)	X1(mm)	409	409	409
	11	Rear Overhang	X2(mm)	470	470	470
	12	Ground Clearance (Bottom of Mast)	H7(mm)	110	110	110
	13	Length to Face of Fork (Without Fork)	L1(mm)	2285	2285	2285
	14	Overall Width	B1(mm)	1082	1082	1082
	15	Mast Lowered Height	H1(mm)	2025	2025	2025
	16	Mast Extended Height (With Backrest)	H4(mm)	4055	4055	4055
	17	Overhead Guard Height	H5(mm)	2160	2160	2160
	18	Turning Radius (Outside)	Wa(mm)	2100	2100	2100
	19	Min.Aisle width for pallets	mm	3700	3700	3700
Performance	20	Travel Speed (No Load)	km/h	14.5	14.5	14.5
	21	Lifting Speed (No Load/Full Load)	mm/sec	550/500	550/500	550/500
	22	Lowering Speed (No Load/Full Load)	mm/sec	400/530	400/530	400/530
	23	Max.Drawbar Pull (Full Load/No Load)	KN	17(14.5)	20.5(17.5)	21(18)
	24	Max.Gradeability (Full Load)	%	20	20	20
Chassis	25	Tyre (Front x 2)	mm	6.50-10-10PR	6.50-10-10PR	6.50-10-10PR
	26	Tyre (Rear x 2)	mm	5.00-8-10PR	5.00-8-10PR	5.00-8-10PR
	27	Front Tread	B2(mm)	890	890	890
	28	Rear Tread	B3(mm)	920	920	920
	29	Wheelbase	Y(mm)	1410	1410	1410
Weight	30	Total Weight	kg	2860	2860	2860
	31	Front Axle Weight Distribution (Full Load)	kg	3815	3815	3815
	32	Rear Axle Weight Distribution (Full Load)	kg	545	545	545
	33	Front Axle Weight Distribution (No Load)	kg	1200	1200	1200
	34	Rear Axle Weight Distribution (No Load)	kg	1660	1660	1660
Power & Transmission	35	Battery	V/Ah	12/90	12/90	12/90
	36	Engine Model		NC485BPG	C240NKFC-01	4TNE92 (EuⅢ & EPAⅢ)
	37	Engine Manufacturer		XINCHAI	ISUZU	YANMAR
	38	Rated Output / r.p.m.	kw	30/2600	34.5/2500	33/2450
	39	Rated Torque / r.p.m.	N·m	131/1800	139/1800	150/1600
	40	No.of Cylinder		4	4	4
	41	Bore x Stroke	mm	85×100	86×102	92×110
	42	Displacement	cc	2270	2369	2659
	43	Fuel Tank Capacity	L	50	50	50
	44	Transmission Type		Powershift & Manual	Powershift &Manual	Powershift & Manual
	45	Transmission Stage (FWD/RVS)		1/1(2/2)	1/1(2/2)	1/1(2/2)
	46	Operating Pressure (For Attachments)	Mpa	14.5	14.5	14.5
