5 ton diesel forklift
Home - Products - Forklift - Diesel Forklift - 5 ton diesel forklift
5 ton forklift with Japan engine or china engine
with 2 stage 3 m mast
LED light
pneumatic tire or solid tire
toyouta seat
Cascade fork
side shift
option:
Full free mast
3 stage mast
| General | 1 | Manufacturer | BeiJing VICGORDAN Industrial Co., Ltd | ||||
| 2 | Model | FD50C | FD50C | FD50J | FD50J | ||
| 3 | Power Type | Diesel | Diesel | Diesel | Diesel | ||
| 4 | Rated Load Capacity | Q(kg) | 5000 | 5000 | 5000 | 5000 | |
| 5 | Load Centre | C(mm) | 500 | 500 | 500 | 500 | |
| Characteristic & Dimension | 6 | Rated Lift Height | H3(mm) | 3000 | 3000 | 3000 | 3000 |
| 7 | Free Lift Height | H2(mm) | 84 | 84 | 84 | 84 | |
| 8 | Fork Size (L×W×T) | mm | 1070×150×50 | 1070×150×50 | 1070×150×50 | 1070×150×50 | |
| 9 | Mast Tilt Angle (F/R, α°/β°) | deg | 6°/12° | 6°/12° | 6°/12° | 6°/12° | |
| 10 | Fork Overhang (Wheel Center to Fork Face) | X1(mm) | 578 | 578 | 578 | 578 | |
| 11 | Rear Overhang | X2(mm) | 614 | 614 | 614 | 614 | |
| 12 | Ground Clearance (Bottom of Mast) | H7(mm) | 175 | 175 | 175 | 175 | |
| 13 | Length to Face of Fork (Without Fork) | L1(mm) | 3125 | 3125 | 3125 | 3125 | |
| 14 | Overall Width | B1(mm) | 1485 | 1485 | 1485 | 1485 | |
| 15 | Mast Lowered Height | H1(mm) | 2260 | 2260 | 2260 | 2260 | |
| 16 | Mast Extended Height (With Backrest) | H4(mm) | 4266 | 4266 | 4266 | 4266 | |
| 17 | Overhead Guard Height | H5(mm) | 2240 | 2240 | 2240 | 2240 | |
| 18 | Turning Radius (Outside) | Wa(mm) | 2830 | 2830 | 2830 | 2830 | |
| 19 | Min.Aisle width for pallets | Ast(mm) | 4680 | 4680 | 4680 | 4680 | |
| Performance | 20 | Travel Speed (No Load) | km/h | 22 | 22 | 22 | 22 |
| 21 | Lifting Speed (No Load/Full Load) | mm/sec | 430 | 430 | 430 | 430 | |
| 22 | Lowering Speed (No Load/Full Load) | mm/sec | 480 | 480 | 480 | 480 | |
| 23 | Max.Drawbar Pull (Full Load) | KN | >21 | >21 | >21 | >21 | |
| 24 | Max.Gradeability (Full Load) | % | ≥20% | ≥20% | ≥20% | ≥20% | |
| Chassis | 25 | Tyre (Front x 2) | mm | 300-15-18PR | 300-15-18PR | 300-15-18PR | 300-15-18PR |
| 26 | Tyre (Rear x 2) | mm | 7.00-12-12PR | 7.00-12-12PR | 7.00-12-12PR | 7.00-12-12PR | |
| 27 | Front Tread | B2(mm) | 1180 | 1180 | 1180 | 1180 | |
| 28 | Rear Tread | B3(mm) | 1190 | 1190 | 1190 | 1190 | |
| 29 | Wheelbase | Y(mm) | 2000 | 2000 | 2000 | 2000 | |
| Weight | 30 | Total Weight | kg | 7100 | 7100 | 7100 | 7100 |
| 31 | Front Axle Weight Distribution (Full Load) | kg | 10500 | 10500 | 10500 | 10500 | |
| 32 | Rear Axle Weight Distribution (Full Load) | kg | 1600 | 1600 | 1600 | 1600 | |
| 33 | Front Axle Weight Distribution (No Load) | kg | 2680 | 2680 | 2680 | 2680 | |
| 34 | Rear Axle Weight Distribution (No Load) | kg | 4420 | 4420 | 4420 | 4420 | |
| Power & Transmission | 35 | Battery | V/Ah | 24/80 | 24/80 | 24/80 | 24/80 |
| 36 | Engine Model | 4110/125-HYB20(NII) | 4DX23-82GG3U(NIII) | S6S（NIII、EIII） | PSI4.3 | ||
| 37 | Engine Manufacturer | XICHAI | XICHAI | Mitsubishi | PSI | ||
| 38 | Rated Output / r.p.m. | kw | 61/2200 | 60/2200 | 52 /2300 | 77/2300 | |
| 39 | Rated Torque / r.p.m. | N·m | 305/1400～1600 | 320/1400～1700 | 248 /1700 | 332.85/1400 | |
| 40 | No.of Cylinder | 4 | 4 | 6 | 4 | ||
| 41 | Bore x Stroke | mm | 110x125 | 102x118 | 94 × 120 | 101.6 x 88.39 | |
| 42 | Displacement | L | 3.857 | 3.857 | 4.966 | 4.29418 | |
| 43 | Fuel Tank Capacity | L | 90 | 90 | 90 | 90 | |
| 44 | Transmission Type | Hydra | Hydra | Hydra | Hydra | ||
| 45 | Transmission Stage (FWD/RVS) | 2/1 | 2/1 | 2/1 | 2/1 | ||
| 46 | Operating Pressure (For Attachments) | Mpa | 19 | 19 | 19 | 19 | |
