2 Ton LPG and Gasoline Forklift

Inquire Now Next Product

Features
Specifications

2 ton forklift with Japan engine or china engine

with 2 stage 3 m mast

LED light

pneumatic tire or solid tire

toyouta seat

Cascade fork

side shift

option:

Full free mast

3 stage mast

1200mm fork

General	1	Manufacturer		BeiJing Vicgordan Industrial Co., Ltd
	2	Model		FL20	FG20	FL20	FGL20
	3	Power Type		LPG	Gasoline	LPG	Gasoline/LPG
	4	Rated Load Capacity	Q(kg)	2000	2000	2000	2000
	5	Load Centre	C(mm)	500	500	500	500
Characteristic & Dimension	6	Rated Lift Height	H3(mm)	3000	3000	3000	3000
	7	Free Lift Height	H2(mm)	100	100	100	100
	8	Fork Size (L×W×T)	mm	1070×120×40	1070×120×40	1070×120×40	1070×120×40
	9	Mast Tilt Angle (F/R, α°/β°)	deg	6°/12°	6°/12°	6°/12°	6°/12°
	10	Fork Overhang (Wheel Center to Fork Face)	X1(mm)	479	479	479	479
	11	Rear Overhang	X2(mm)	520	520	520	520
	12	Ground Clearance (Bottom of Mast)	H7(mm)	130	130	130	130
	13	Length to Face of Fork (Without Fork)	L1(mm)	2660	2660	2660	2660
	14	Overall Width	B1(mm)	1150	1150	1150	1150
	15	Mast Lowered Height	H1(mm)	2055	2055	2055	2055
	16	Mast Extended Height (With Backrest)	H4(mm)	4070	4070	4070	4070
	17	Overhead Guard Height	H5(mm)	2215	2215	2215	2215
	18	Turning Radius (Outside)	Wa(mm)	2365	2365	2365	2365
	19	Min.Aisle width for pallets	Ast(mm)	4120	4120	4120	4120
Performance	20	Travel Speed (No Load)	km/h	19	19	19	19
	21	Lifting Speed (No Load/Full Load)	mm/sec	470/450	470/450	470/450	470/450
	22	Lowering Speed (No Load/Full Load)	mm/sec	350/470	350/470	350/470	350/470
	23	Max.Drawbar Pull (Full Load/No Load)	KN	17(13.5)	17(13.5)	17(13.5)	17(13.5)
	24	Max.Gradeability (Full Load)	%	20	20	20	20
Chassis	25	Tyre (Front x 2)	mm	7.00-12-12PR	7.00-12-12PR	7.00-12-12PR	7.00-12-12PR
	26	Tyre (Rear x 2)	mm	6.00-9-10PR	6.00-9-10PR	6.00-9-10PR	6.00-9-10PR
	27	Front Tread	B2(mm)	970	970	970	970
	28	Rear Tread	B3(mm)	980	980	980	980
	29	Wheelbase	Y(mm)	1650	1650	1650	1650
Weight	30	Total Weight	kg	3385	3385	3385	3385
	31	Front Axle Weight Distribution (Full Load)	kg	4846	4846	4846	4846
	32	Rear Axle Weight Distribution (Full Load)	kg	538	538	538	538
	33	Front Axle Weight Distribution (No Load)	kg	1354	1354	1354	1354
	34	Rear Axle Weight Distribution (No Load)	kg	2031	2031	2031	2031
Power & Transmission	35	Battery	V/Ah	12/90	12/90	12/90	12/90
	36	Engine Model		PSI2.4L	K25	K25	K25
	37	Engine Manufacturer		Mitsubishi	NISSAN	NISSAN	NISSAN
	38	Rated Output / r.p.m.	kw	46/2700	44.2/2500	44.2/2500	44.2/2500
	39	Rated Torque / r.p.m.	N·m	168 /1600	186.2/1600	186.2/1600	186.2/1600
	40	No.of Cylinder		4	4	4	4
	41	Bore x Stroke	mm	86.50X100.00	92×93	92×93	92×93
	42	Displacement	cc	2351	2472	2472	2472
	43	Fuel Tank Capacity	L	50	50	50	50
	44	Transmission Type		Powershift ( Manual)	Powershift ( Manual)	Powershift ( Manual)	Powershift ( Manual)
	45	Transmission Stage (FWD/RVS)		1/1(2/2)	1/1(2/2)	1/1(2/2)	1/1(2/2)
	46	Operating Pressure (For Attachments)	Mpa	17.5	17.5	17.5	17.5
